Need a low cost, low power 1GbE adapter for your HPE ProLiant Gen 9 server? The HPE Ethernet 1Gb 4-port 366T Adapter features a single chip solution, further reducing power requirements for 4 ports of 1 Gb Ethernet. The HPE 366T is PCI Express 2.1 x4 based on the latest Intel Ethernet Controller I350 designed for use with select HPE ProLiant Gen9 rack, tower and density optimized servers.
Key Selling Points
- Fully integrated (bridgeless) Intel Ethernet I350 Controller, optimized for the new Integrated I/O and Data Direct I/O technologies.
Product Features
- New Level of Performance and Power Management in a 1GbE Card for HPE ProLiant Gen9 DL/ML/XL Servers
Fully integrated (bridgeless) Intel Ethernet I350 Controller, optimized for the new Integrated I/O and Data Direct I/O technologies.
Quad port bandwidth, Gigabit PCI Express 2.1 NIC, with full height or low profile brackets.
New I/O technologies reduce system power, increase I/O performance and reduce I/O latency.
What's in the Box
- HPE 366T
- Full-height bracket, half-height bracket
Specifications
| General | |
|---|---|
| Device Type | Network adapter |
| Form Factor | Plug-in card - low profile |
| Interface (Bus) Type | PCI Express 2.1 x4 |
| PCI Specification Revision | PCIe 2.1 |
| Networking | |
| Ports | Gigabit Ethernet x 4 |
| Connectivity Technology | Wired |
| Data Link Protocol | GigE |
| Data Transfer Rate | 1 Gbps |
| Remote Management Protocol | SNMP |
| Status Indicators | Port transmission speed, link/activity |
| Features | Fault tolerance, load balancing, Jumbo Frames support, PXE support, Large Send Offload (LSO), Extended Message-Signaled Interrupts (MSI-X) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.3az |
| Processor / Memory | |
| Processor | 1 x I350 - Intel |
| Expansion / Connectivity | |
| Interfaces | 4 x Ethernet 1000 - RJ-45 |
| Miscellaneous | |
| Included Accessories | Full-height bracket, half-height bracket |
| Compliant Standards | UL, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, WEEE, RoHS, FCC Part 15 A, ICES, VCCI V-3 Class A ITE |
| Software / System Requirements | |
| OS Required | SuSE Linux Enterprise Server 11 for x86/AMD64/Intel EM64T, SuSE Linux Enterprise Server 10 for x86/AMD64/Intel EM64T, Microsoft Windows Server 2008, Microsoft Windows Server 2008 Enterprise, Microsoft Windows Server 2008 Standard, Microsoft Windows HPC Server 2008, Oracle Solaris 10, Microsoft Windows Small Business Server 2011, Red Hat Enterprise Linux 6.1, Red Hat Enterprise Linux 5.7, Citrix XenServer 6.0, VMware vSphere 5.0, VMware vSphere 4.1 |
| Dimensions & Weight | |
| Depth | 5.3 in |
| Height | 2.7 in |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 131 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Compatibility Information | |
| Designed For | HPE ProLiant DL180 Gen9, DL180 Gen9 Base, DL180 Gen9 Entry, DL180 Gen9 Storage, DL20 Gen9, DL20 Gen9 Entry, DL20 Gen9 Performance, DL20 Gen9 Solution, DL360 Gen10, DL360 Gen10 Base, DL360 Gen10 Entry, DL360 Gen10 High Performance, DL360 Gen10 Low, DL360 Gen10 Performance, DL360 Gen10 Solution, DL560 Gen10, DL560 Gen10 Base, DL560 Gen10 Entry, DL560 Gen10 Performance, DL560 Gen9, DL560 Gen9 Base, DL560 Gen9 Entry, DL560 Gen9 Performance, DL80 Gen9 Entry, ML110 Gen10, ML110 Gen10 Performance, ML110 Gen10 Solution, ML110 Gen9, ML110 Gen9 Base, ML110 Gen9 Entry, ML30 Gen9 Entry, ML30 Gen9 Solution, ML350 Gen10, ML350 Gen10 Base, ML350 Gen10 Entry, ML350 Gen10 Performance, ML350 Gen10 Solution, ML350 Gen10 Sub-Entry, XL170r Gen10, XL230k Gen10 Compute Tray, XL450 Gen10 ¦ HPE SimpliVity 380 Gen9 Node ¦ HPE StoreEasy 1450, 1850, 3850 Gateway Single Node |
