727060-B21 - HP FlexFabric 10Gb 2-port 556FLR-SFP+ Adapter
MFG Part
727060-B21
Inventory
0
MSRP
$629.00
Condition
New
Availability
Available
Standard Warranty
Limited warranty - 1 year
Do you need a high-performance 10 Gb Ethernet adapter for your HPE ProLiant Gen9 server family? The HPE FlexFabric 10Gb 2-port 556FLR-SFP+ Adapter is installed in the FlexibleLOM socket in the ProLiant Gen9 Rack/Tower servers. The adapter offers 10GbE FlexibleLOM with Tunnel Offload feature. It provides full-featured, high-performance, converged 10 Gb Ethernet that accelerates IT services and increases data center efficiency. Tunnel Offload provides efficient overlay networking to increase VM migration flexibility and network scale with minimal impact to performance. Traditional layer 2 networks limit mobility and scale of virtualized and multi-tenant workloads.
Key Selling Points
- The HPE FlexFabric 10Gb 2-port 556FLR-SFP+ Adapter is the industryƒÃƒ‚¢Ãƒ‚‚¬Ã‚„¢s first product to converge FCoE with LAN traffic on a single Ethernet fabric, reducing the complexity for managing multiple traffic in the data center.
- The HPE FlexFabric 10Gb 2-port 556FLR-SFP+ Adapter uses Tunnel Offload and a 10GbE bandwidth improvement to take full advantage of overlay networking.
Product Features
- Lower Costs and Deliver Faster Services by Converging FCoE with LAN Traffic on a Single Wire
The HPE FlexFabric 10Gb 2-port 556FLR-SFP+ Adapter is the industry's first product to converge FCoE with LAN traffic on a single Ethernet fabric, reducing the complexity for managing multiple traffic in the data center.
This adapter can cost-effectively increase server I/O bandwidth and avoid bottlenecks in your HPE ProLiant Gen9 Server today and in the future.
Simplify the infrastructure by reducing 87% of the hardware compared to previous 1GbE generations, reducing operational costs and acquisition costs.
Provide up to 40 Gb/s of converged bi-directional bandwidth, helping to alleviate network bottlenecks. - Improve Network Virtualization Performance and Scale with Tunnel Offload
The HPE FlexFabric 10Gb 2-port 556FLR-SFP+ Adapter uses Tunnel Offload and a 10GbE bandwidth improvement to take full advantage of overlay networking.
You can increase I/O throughput up to 129%, and reduce CPU and power consumption by 42% and 122% respectively using Tunnel Offload.
Increase the scale of VMs/VLANs beyond the traditional limit of 4,096.
Simplify network services provisioning.
Get up to 4x improvement in small packet performance.
Specifications
| General | |
|---|---|
| Device Type | Network adapter |
| Interface (Bus) Type | PCI Express 3.0 x8 |
| PCI Specification Revision | PCIe 3.0 |
| Networking | |
| Connectivity Technology | Wired |
| Data Link Protocol | 10 GigE |
| Data Transfer Rate | 10 Gbps |
| Features | Auto-negotiation, wake on LAN (WOL), Jumbo Frames support, PXE support, Large Send Offload (LSO), Receive Side Scaling (RSS) |
| Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap, IEEE 802.3az, IEEE 802.1Qau |
| Processor / Memory | |
| Processor | 1 Emulex |
| RAM | 128 MB |
| Miscellaneous | |
| Compliant Standards | FCC Class A certified, UL, CISPR 22 Class A, EN 60950, VCCI Class A ITE, EN55024, EN55022 Class A, ICES-003 Class A, RoHS, MIC Class A, ACA, ACPI 1.1, BSMI Class A |
| Software / System Requirements | |
| OS Required | SunSoft Solaris 10, SuSE Linux Enterprise Server 11, Microsoft Windows Server 2008 R2, SuSE Linux Enterprise Server 10, Microsoft Windows Server 2008, Microsoft Windows HPC Server 2008, Red Hat Enterprise Linux 6, Red Hat Enterprise Linux 5.x, VMware ESX 4.1, VMware ESX 4.0 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 131 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Compatibility Information | |
| Designed For | HPE ProLiant DL20 Gen9, DL20 Gen9 Entry, DL20 Gen9 Performance, DL20 Gen9 Solution, DL380 Gen9 High Performance, DL560 Gen9, DL560 Gen9 Base, DL560 Gen9 Entry, DL560 Gen9 Performance, XL170r Gen9, XL190r Gen9, XL230a Gen9 Compute Tray, XL230a Gen9 Compute Tray (12G), XL230a Gen9 Compute Tray (6G), XL230a Gen9 NHP Compute Tray (12G) ¦ HPE StoreEasy 1850, 3850 Gateway Single Node |
