C8R38A - HPE StoreFabric SN1100E 16Gb Single Port Fibre Channel Host Bus Adapter

MFG Part

C8R38A

Inventory

0

MSRP

$1,980.00

Condition

New

Availability

Available

Standard Warranty

Limited warranty - 1 year



Looking for a high-bandwidth HBA solution to meet the requirements of increasing server virtualization and consolidation? Finding it difficult to realize the full bandwidth potential of your server running I/O intensive applications? The HPE StoreFabric SN1100E 16Gb Host Bus Adapters deliver twice the I/O performance of 8 Gb HBAs, it takes storage networking performance and efficiency to the next level. They enable rapid storage and retrieval of critical information when using high bandwidth cloud applications and storage intensive applications such as backup, database transactions and rich media. Designed for increased virtual machine density and bandwidth requirements, the SN1100E 16Gb HBA products enable more applications and virtual machines to run on a single server and port, resulting in reduced cabling. The SN1100E 16Gb HBAs are backward compatible with 8 Gb and 4 Gb networks and will protect your current and future IT investments.

Key Selling Points

  • The HPE StoreFabric SN1100E 16Gb Host Bus Adapters deliver twice the I/O performance of 8 Gb Fibre Channel (FC) HBAs.
  • The HPE StoreFabric SN1100E 16Gb Host Bus Adapters are ideal for the implementation of virtual servers with the power to drive multiple virtual machines.
  • The HPE StoreFabric SN1100E 16Gb Host Bus Adapters allow IT departments to do more with less: less hardware, less power, less cooling, less personnel, and less budget.

Product Features

  • High-performance, Fibre Channel Host Bus Adapters
    The HPE StoreFabric SN1100E 16Gb Host Bus Adapters deliver twice the I/O performance of 8 Gb Fibre Channel (FC) HBAs.
    Moving to 16 Gb technology provides the infrastructure required for the more powerful servers and data intensive applications in virtualized environments.
    When using storage intensive applications like backup/restore, database transactions, virtualization and rich media, the improved I/O performance enables faster storage and retrieval of data.
  • Outstanding Fibre Channel Host Bus Adapters for Virtualization
    The HPE StoreFabric SN1100E 16Gb Host Bus Adapters are ideal for the implementation of virtual servers with the power to drive multiple virtual machines.
    Allows a single port to acquire multiple N Port IDs, reducing the need for additional physical ports.
    Data center administrators do not need to concern themselves with multiple requests from the virtualized servers potentially creating conflict.
    Improves host utilization and enhances application performance.
    Allows power savings resulting in lower operating expenditures.
  • Four Ports for Additional Bandwidth
    The HPE StoreFabric SN1100E 16Gb Host Bus Adapters allow IT departments to do more with less: less hardware, less power, less cooling, less personnel, and less budget.
    They optimize existing resources by deploying an effective adaptive server solutions.
    Scale physical resources through consolidation and virtualization.

What's in the Box

  • (1) 16 Gb 1-port Host Bus Adapter with standard bracket, (1) 16 Gb/s SFP+, low-profile bracket, documentation

Specifications

General
Device TypeHost bus adapter
Form FactorPlug-in card - low profile
Interface (Bus) TypePCI Express 3.0 x8
Networking
Ports16Gb Fibre Channel x 1
Connectivity TechnologyWired
Cabling TypeFiber optic
Data Link Protocol16Gb Fibre Channel (SW)
Data Transfer Rate14.025 Gbps
FeaturesAuto-negotiation
Expansion / Connectivity
Expansion Slots1 (total) / 0 (free) x SFP+
Interfaces1 x 16Gb Fibre Channel (Short Wave) - LC multi-mode
Miscellaneous
Included AccessoriesLow-profile bracket, full-height bracket, 16Gb SFP+
Software / System Requirements
OS RequiredSUSE Linux Enterprise Server, Red Hat Enterprise Linux, Microsoft Windows Server 2008 (32/64-bits), VMware ESXi, VMware ESX, Microsoft Windows Server 2008 R2 (64-bits)
Dimensions & Weight
Width1.4 in
Depth9.1 in
Height5.1 in
Environmental Parameters
Min Operating Temperature32 °F
Max Operating Temperature113 °F
Humidity Range Operating15 - 80% (non-condensing)
Compatibility Information
Designed ForHPE ProLiant DL160 Gen8, DL160 Gen8 Base, DL160 Gen8 Entry, DL160 Gen8 Performance, DL360e Gen8, DL360e Gen8 Base, DL360e Gen8 Entry, DL360e Gen8 Performance, DL360e Gen8 Special Server, DL360p Gen8, DL360p Gen8 Base, DL360p Gen8 CMS, DL360p Gen8 Entry, DL360p Gen8 High Performance, DL360p Gen8 Performance, DL380e Gen8, DL380e Gen8 Base, DL380e Gen8 Entry, DL380e Gen8 High Performance, DL380e Gen8 Storage, DL380p Gen8, DL380p Gen8 Base, DL380p Gen8 Entry, DL380p Gen8 High Performance, DL380p Gen8 Performance, DL380p Gen8 Special, DL385p Gen8, DL385p Gen8 Dedicated Workload, DL385p Gen8 Entry, DL385p Gen8 Maximized Consolidation, DL385p Gen8 Storage, DL385p Gen8 Storage Centric, DL560 Gen8, DL560 Gen8 Base, DL560 Gen8 Entry, DL560 Gen8 Performance, ML350p Gen8, ML350p Gen8 Base, ML350p Gen8 Entry, ML350p Gen8 Performance, ML350p Gen8 Special Server, SL230s Gen8 1U Left Half Width Tray, SL230s Gen8 1U Right Half Width Tray, SL230s Gen8 Base 1U Left Tray Server, SL230s Gen8 Base 1U Right Tray Server, XL230a Gen9 Compute Tray, XL230a Gen9 Compute Tray (12G), XL230a Gen9 Compute Tray (6G) ¦ HPE StoreEasy 3850 Gateway Single Node
